2B BA surface and SUS316L Carbon Steel Strip with 0.3-1.0mm(+-0.01mm) thickness
SUS316L cold rolled stainless steel strip with thickness:0.3-1.0mm(+-0.01mm), width:20-600mm HV160-400 Surface:2B BA
Applications:
Apply to used as important in the chemical industry, chemical fiber, fertilizer and other industrial corrosion-resistant materials. In addition to the good resistance to atmospheric corrosion and high-temperature strength characteristics of the harshness of the conditions under corrosive excellent, excellent work hardening, marine equipment, paper and other production equipment in its resistance to intergranular acetate equipment. Their resistance to intergranular good corrosion.
Description:
SUS316L Japanese the SUS series of stainless steel, carbon content than 316 steel lower resistance to intergranular corrosion better. Apply to used as a the important corrosion resistant material in the chemical industry, chemical fiber, fertilizer and other industrial. In addition to the good resistance to atmospheric corrosion and high-temperature strength characteristics of the harshness of the conditions under corrosive excellent, excellent work hardening, marine equipment, paper and other production equipment in its resistance to intergranular acetate equipment. Their resistance to intergranular corrosion the good .316 L stainless steel, the maximum carbon content of 0.03, can be used for welding can not carry out the purpose of of annealing and need maximum corrosion resistance.
Specifications:
Chemical composition:
|
Name
|
C
|
Si
|
Mn
|
P
|
S
|
Cr
|
Mo
|
Ni
|
|
316L
|
≤0.03
|
≤1.00
|
≤2.00
|
≤0.045
|
≤0.030
|
16.00-18.00
|
2.00-3.00
|
12.00-15.00
|
Mechanical Properties:
|
Condition
|
Tensile strength
Rm N/mm2
|
Yield strength
RP0.2 N/mm2
|
Elongation
As %
|
|
Annealed
|
520
|
205
|
40
|
Thinckness:0.3-1.0mm(±0.01mm)
Width: 20-600mm
Hardness: HV160-400
thickness Tolerance:±0.01mm
width Tolerance:±0.02mm
surface: good arc edge,bright, no scraping wire
The commom size:
0.1*160mm 0.1*300mm 0.1*140mm
0.06*200mm 0.06*300mm 0.06*400mm
0.2*20mm, 0.2*30mm 0.2*40mm
0.2*2mm 0.2*3mm 0.2*4mm
other sizes as your requirements to produce.
Density:
|
Steel Grade
|
Density(g/cm3)
|
|
201,202,301,302,303, 304,304L,305,321
|
7.93
|
|
316,316L,316S,347,309S,310,310S
|
7.98
|
|
405,410,420
|
7.75
|
|
409,430,434
|
7.7
|
Stainless steel theoretical weight formula:
Weight (kg) = thickness (mm) × width (mm) x length (mm) × density values
Stainless steel gravity:
Chromium stainless take 7.75 ton / M3
Chrome-nickel stainless steel take 7.93 ton / M3
Iron take 7.87 ton / M3
Competitive Advantage:
First-class quality, complete specifications, reasonable price, timely delivery and rigorous specified according to customer requirements, suited materials for basic principles, to allow customers to buy satisfaction with assured.
Product Tags:
|
|
2B BA surface and SUS316L Carbon Steel Strip with 0.3-1.0mm(+-0.01mm) thickness Images
|
